Handheld electric screwdriver with compact size for tight spaces and steel gear transmission for LED module and lighting fixture manufacturing
Built for LED module and lighting fixture manufacturing, this handheld electric screwdriver has a compact size for tight spaces and steel gear transmission. It accesses narrow areas easily, delivers durable, smooth operation via steel gears, ensures precise fastening, and streamlines assembly tasks for lighting production.
Product Description
Handheld electric screwdriver with compact size for tight spaces and steel gear transmission for LED module and lighting fixture manufacturing
Features of screw fastener machine
1.Single-handed operation—simply hold the item and position it with the screw point for fastening.
2.High-speed tightening with accurate torque control, and easy torque adjustments on the handheld driver paired with a screw feeder.
3.Compact and lightweight electric screwdriver ensures clear visibility for operators and is effortless to carry or store.
4.Integrated low-screw warning function notifies users when replenishment is needed.
5.Automated screw separation prevents contamination caused by manual handling.
6.Sensor-based mechanism dispenses screws individually, eliminating duplicate feeding.
7.Delivers fast throughput, achieving approximately 50–70 screws per minute.
|
Model |
BBA-100LS |
| Voltage | 110/220V 50/60HZ |
| Feeder capacity | 1000pcs (depends on screw size) |
| Air pressure | 0.5~0.7MPa |
| Conveying distance | 1~3meters |
| Feeder mode | Vibratory feeder |
| Screw delivery method | Auto blowing type feeder |
| Working efficiency | 50~70pcs/minute |
| Applicable screws | M2~M4 |
| Screw head | Tapping screw, pan head, stainless steel etc… |
| Dimension | 35*40*22CM |
| Weight | 20KG |
Product Description
Applicable screws
Package
